| - | 3GEN Masonry Products Barrel Anchor Metal Stud | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

Galvanized steel screw and washer anchor with projecting eye to receive hot dip galvanized steel wire tie. Available in polymer coated finish.

applications

Masonry veneer anchor screw attached to metal and wood stud framed exterior walls with continuous insulation. Use with or without seismic clips and continuous rods.

Limitations

Install anchor after continuous wall insulation. Maximum 6 inch sheathing plus insulation thickness. Maximum 7 inch veneer wire tie length.

warranty

-

| - | 3GEN Masonry Products Cell Vent | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

044313 04-4313 04-4313. 04 43 13 04-43-13- Stone Masonry Veneer

Division 04

Cloud

Cellular polypropylene co-polymer vent to enable air flow and drainage of masonry cavity walls without insect intrusion. Available in six standard colors and two sizes to accommodate standard modular and jumbo brick head joints.

applications

Replace brick masonry head mortar joint to create cavity wall weeps and vents. Install as weeps above flashing. Install as vents below flashing. Install with 1/8 inch set back from exterior wall face.

Limitations

Prevent mortar droppings within cavity from clogging weeps.

warranty

-

| - | 3GEN Masonry Products Dovetail Triangle | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

Galvanized steel triangle wire veneer tie fitted with dovetail head for insertion into dovetail slot. Available in hot dip galvanized finish.

applications

Masonry veneer anchor for concrete and masonry substrates with or without continuous insulation. Use with or without seismic clips and continuous rods.

Limitations

Requires dovetail slot cast into concrete substrate or surface mounted on concrete or masonry substrate. Maximum 5 inch dovetail triangle length.

warranty

-

| - | 3GEN Masonry Products Genflash | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

044313 04-4313 04-4313. 04 43 13 04-43-13- Stone Masonry Veneer

Division 04

Cloud

Composite polyethylene sheet, self-adhered, flexible flashing with bonded clear adhesive in 4 to 36 inch widths. Accessories include stainless steel termination bars, drip edges, prefabricated inside and outside corners, prefabricated end dams, and sealants.

applications

Self-adhered, self sealing, masonry through wall flashing used with concrete, concrete masonry, and sheathing structural backup. Primer is not required.

Limitations

Requires termination bar to secure top edge. Requires support across masonry cavity air space.

warranty

3GEN Masonry Products, Inc. (“3GEN”) warrants that its GENFLASH Membrane (“Product”) will be free from material defects that cause water penetration through the membrane for ten (10) years from the date of sale, subject to the terms, conditions, and limitations stated herein. This warranty applies solely to GENFLASH installed as an in-cavity wall flashing product to channel water out of weep holes, in accordance with 3GEN’s installation instructions. Other installation methods are explicitly excluded from this warranty.

-

| - | 3GEN Masonry Products Genflash Copper | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

3, 5, or 7 oz copper sheet, laminated, flexible flashing bonded to polymeric fabric on both faces in 12 to 36 inch widths. Accessories include aluminum and stainless steel termination bars, stainless steel drip edges, prefabricated inside and outside corners, prefabricated end dams, and sealants.

applications

Masonry through wall flashing used with concrete, concrete masonry, and sheathing structural backup.

Limitations

Requires termination bar to secure top edge. Requires support across masonry cavity air space.

warranty

Life of wall warranty. 3GEN Masonry Products, Inc. (“3GEN”) warrants that its GENFLASH Membrane (“Product”) will be free from material defects that cause water penetration through the membrane for ten (10) years from the date of sale, subject to the terms, conditions, and limitations stated herein. This warranty applies solely to GENFLASH installed as an in-cavity wall flashing product to channel water out of weep holes, in accordance with 3GEN’s installation instructions. Other installation methods are explicitly excluded from this warranty.

-

| - | 3GEN Masonry Products Genflash SS | 3Gen Masonry Products

Division

044313 04-4313 04-4313. 04 43 13 04-43-13- Stone Masonry Veneer

Division 04

Cloud

Type 304 stainless steel, laminated, flexible flashing with bonded polymeric fabric backing in 12 to 36 inch widths. Accessories include stainless steel termination bars, drip edges, prefabricated inside and outside corners, prefabricated end dams, and sealants.

applications

Masonry through wall flashing used with concrete, concrete masonry, and sheathing structural backup.

Limitations

Requires termination bar to secure top edge. Requires support across masonry cavity air space.

warranty

Life of wall warranty. 3GEN Masonry Products, Inc. (“3GEN”) warrants that its GENFLASH Membrane (“Product”) will be free from material defects that cause water penetration through the membrane for ten (10) years from the date of sale, subject to the terms, conditions, and limitations stated herein. This warranty applies solely to GENFLASH installed as an in-cavity wall flashing product to channel water out of weep holes, in accordance with 3GEN’s installation instructions. Other installation methods are explicitly excluded from this warranty.

-

| - | 3GEN Masonry Products Genflash SS SA | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

Type 304 stainless steel, self-adhered, laminated, flexible flashing with bonded butyl adhesive and release liner in 12 to 36 inch widths. Accessories include stainless steel termination bars, drip edges, prefabricated inside and outside corners, prefabricated end dams, and sealants.

applications

Self-adhered masonry through wall flashing used with concrete, concrete masonry, and sheathing structural backup. Primer is not required.

Limitations

Requires termination bar to secure top edge. Requires support across masonry cavity air space.

warranty

Life of wall warranty. 3GEN Masonry Products, Inc. (“3GEN”) warrants that its GENFLASH Membrane (“Product”) will be free from material defects that cause water penetration through the membrane for ten (10) years from the date of sale, subject to the terms, conditions, and limitations stated herein. This warranty applies solely to GENFLASH installed as an in-cavity wall flashing product to channel water out of weep holes, in accordance with 3GEN’s installation instructions. Other installation methods are explicitly excluded from this warranty.

-

| - | 3GEN Masonry Products H-10 | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

Galvanized steel plate veneer anchor with projecting tab to receive veneer triangle. Available in hot dip galvanized finish.

applications

Masonry veneer anchor screw attached to stud framed, concrete, or masonry exterior walls. Use with or without seismic clips and continuous rods.

Limitations

Do not install anchor over continuous wall insulation. Maximum 6 inch wide cavity. Maximum 9 inch veneer triangle length.

warranty

-

| - | 3GEN Masonry Products H-13-V | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

Galvanized steel plate veneer anchor with vertical projecting leg protruding through continuous insulation to receive veneer triangle. Available in hot dip galvanized finish.

applications

Masonry veneer anchor screw attached to stud framed, concrete, or masonry exterior walls. Use with or without seismic clips and continuous rods.

Limitations

Install anchor before continuous wall insulation. Maximum 4.5 inch wide cavity with maximum 4.5 inch thick continuous insulation. Maximum 9 inch veneer triangle length.

warranty

-

| - | 3GEN Masonry Products Ladder Eye | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

Ladder style with projecting eyes, galvanized steel, horizontal joint reinforcing for masonry cavity wall joints. Available in standard, heavy duty, and extra heavy duty side and cross wire diameters with mill or hot dip galvanized finish.

applications

Cavity walls with masonry veneer and concrete masonry backup at exterior walls. Use with loadbearing and non-loadbearing, ungrouted and vertically reinforced and grouted concrete masonry. Use with veneer hooks with or without seismic clips and continuous rods.

Limitations

Maximum 12 inch concrete masonry wythe. Maximum 6 inch wide cavity with maximum 4 inch thick continuous insulation. Maximum 7 inch veneer hook length.

warranty

-

| - | 3GEN Masonry Products Ladder Reinforcing | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

Ladder style, galvanized steel, horizontal joint reinforcing for unit masonry joints. Available in standard, heavy duty, and extra heavy duty side and cross wire diameters with mill or hot dip galvanized finish.

applications

Single wythe concrete masonry exterior walls and interior partitions. Use with loadbearing and non-loadbearing, ungrouted and vertically reinforced and grouted concrete masonry.

Limitations

Maximum 12 inch concrete masonry wythe.

warranty

-

| - | 3GEN Masonry Products Mortar Clear | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

044313 04-4313 04-4313. 04 43 13 04-43-13- Stone Masonry Veneer

Division 04

Cloud

Dovetail shaped drainage mesh formed from open mesh, woven, structural, polymer strands. Available in four thicknesses ranging from 0.4 to 2 inches. Compressible to fit multiple cavity widths.

applications

Fill masonry cavities above flashings to keep weep holes open by catching mortar droppings on two levels above weeps.

Limitations

Prevent mortar droppings within cavity from clogging weeps.

warranty

-

| - | 3GEN Masonry Products Rebar Positioner | 3Gen Masonry Products

Division

042000 04-2000 04-2000. 04 20 00 04-20-00- Unit Masonry

Division 04

Cloud

applications

Limitations

warranty
