Raynor Garage Doors | The Specifier's Portal by Conspectus Cloud and 4specs

Sales support:

architectsupport@raynor.com

+1 720-663-8838

Technical support:

architectsupport@raynor.com

+1 720-663-8838

Website:

https://raynor.com/

additional info:

Powder Coat Finsh

about

Quality in Craftsmanship, Integrity in Partnership Since 1944 For over 80 years, Raynor Garage Doors has been an industry leader as a family-owned garage door manufacturer located in Dixon, IL. We proudly manufacture a wide range of premium residential, commercial, and industrial garage door products and operators, sold through our network of trusted professional installing dealers and national partners. Raynor’s superior support, commitment to quality, dedication to innovation, and trade integrity make us a consistent partner of choice for dealers, architects, and homeowners.

Address

Raynor Garage Doors 1101 East River Road Dixon, IL 61021

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | AlumaView AV300 | Raynor Garage Doors

Division

3" thick, heavy-duty aluminum sectional rail and stile door with full-view glazing for large commercial openings.

applications

Aluminum full view door with focus on increased durability and higher wind load ratings.

Limitations

Available in sizes up to 24' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against defects in material and workmanship is five (5) years. Window components warranty is (3) years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | AlumaView AV175 | Raynor Garage Doors

Division

1-3/4" thick, aluminum sectional door, streamlined rail construction, with full-view glazing designed to maximize daylight and visibility.

applications

Aluminum full view door for maximum visibility and design options.

Limitations

Available in sizes up to 16' wide x 14' high.

warranty

Standard hardware warranty is one year. Section warranty against defects in material and workmanship is five (5) years. Window components warranty is (3) years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | AlumaView AV200 | Raynor Garage Doors

Division

2" thick, heavy-duty aluminum sectional rail and stile door. Increase thermal performance with ThermaXPS™.

applications

Aluminum full view door for maximum visibility and design options.

Limitations

Available in sizes up to 24' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against defects in material and workmanship is five (5) years. Window components warranty is (3) years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | Aspen AP138C | Raynor Garage Doors

Division

1-3/8” thick steel gauge door with a 0.20 U-Factor (R-Value 13.0).

applications

Commercial applications that require a door with residential design and color options.

Limitations

Available in sizes up to 20' wide x 16' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | Aspen AP200C | Raynor Garage Doors

Division

2″ thick, thermally efficient residential steel garage door, featuring NeuFoam™ polyurethane insulation that fills 100% of the section’s interior.

applications

For commercial applications that require residential design options and colors.

Limitations

Available in sizes up to 24' wide x 16' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083323 08-3323 08-3323. 08 33 23 08-33-23- Overhead Coiling Doors

Division 08

08 -

33

23 -

| - | Duracoil | Raynor Garage Doors

Division

Rolling service door. Aluminum, steel, or stainless steel slats available in multiple gauges for durable performance in commercial and industrial environments. Available with flat, insulated flat, small contour, large contour, or perforated slat profiles to accommodate functional and aesthetic requirements.

applications

DuraCoil rolling services doors can be used in both exterior and interior applications including corrosive environments. They are also suitable for high usage applications where durability is important.

Limitations

DuraCoil rolling service doors can be manufactured in sizes up to 40' wide.

warranty

Standard warranty is one year.

Warranty Details

083323 08-3323 08-3323. 08 33 23 08-33-23- Overhead Coiling Doors

Division 08

08 -

33

23 -

| - | DuraCoil HP | Raynor Garage Doors

Division

High-performance rolling steel door engineered for high-cycle durability and security.

applications

Optimized for high-traffic environments where standard rolling steel doors lack the necessary speed and cycle life.

Limitations

Available in sizes up to 20' wide x 14' high.

warranty

Standard warranty is two years or 300,000 cycles (whichever comes first).

Warranty Details

083326 08-3326 08-3326. 08 33 26 08-33-26- Overhead Coiling Grilles

Division 08

08 -

33

26 -

| - | DuraGrille | Raynor Garage Doors

Division

Rolling security grille, straight or brick pattern, provides visibility, airflow, and controlled access for commercial applications. Exterior and interior applications.

applications

Openings where security but also visibility and air circulations are important.

Limitations

Available in sizes up to 35' wide and 24' high.

warranty

Standard warranty is one year.

Warranty Details

083323 08-3323 08-3323. 08 33 23 08-33-23- Overhead Coiling Doors

Division 08

08 -

33

23 -

| - | DuraShutter | Raynor Garage Doors

Division

Compact rolling counter shutter designed to secure concession and service openings.

applications

Counter window openings.

Limitations

Available in sizes up to 20' wide x 10' high.

warranty

Standard warrant is one year.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | EnergyCore EC200 | Raynor Garage Doors

Division

Steel two-sided door, features a core of polystyrene insulation laminated between two high-strength 26-gauge steel skins. EC200 is available in six colors, two panel styles and optional windows to meet the need of any application.

applications

Applications requiring a standard insulated door.

Limitations

Available in sizes up to 24' wide x 16' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | EnergyCore EC224 | Raynor Garage Doors

Division

Steel two-sided door, features a core of polystyrene insulation laminated between a 26-gauge interior steel and a 24-gauge exterior steel skin. The EC224 is available in white and is perfect for applications where thicker steel is specified.

applications

Applications requiring a standard insulated door.

Limitations

Available in sizes up to 24' wide and 16' high

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083323 08-3323 08-3323. 08 33 23 08-33-23- Overhead Coiling Doors

Division 08

08 -

33

23 -

| - | FireCurtain | Raynor Garage Doors

Division

Fire-rated rolling counter shutter providing code-compliant fire protection at service openings. Provided with fusible links that automatically release to close the door at 165°F, the shutter can also be triggered by smoke and heat detectors, a building’s alarm system, or LM21 fail-safe release devices. All FireCurtain counter shutters comply with UL, C-UL, FM, and CSFM requirements for 3-hour, 1-1/2-hour, or ¾-hour fire ratings.

applications

Any counter windows that require a fire rated counter shutter.

Limitations

Available in sizes up to 12' wide and 8' high.

warranty

Standard warranty is one year.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | SteelPro SP20 | Raynor Garage Doors

Division

Heavy-duty commercial steel door constructed with 2" thick sections and 20-gauge steel for maximum durability in demanding environments. Optional insulation enhances thermal and acoustic performance, while ColorWave™ finishes provide coordinated color options.

applications

Applications where a heavy-duty non-insulated door is required.

Limitations

Available in sizes up to 32' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | SteelPro SP24 | Raynor Garage Doors

Division

Steel door constructed with 2" thick sections and 24-gauge steel to provide reliable performance across a broad range of applications. Optional insulation improves thermal and acoustic performance, and a wide selection of standard colors and ColorWave™ finishes supports design flexibility.

applications

Applications where a standard 24ga non-insulated door is needed.

Limitations

Available in sizes up to 32' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | SteelPro SP24C | Raynor Garage Doors

Division

Steel door constructed with 2" thick sections and nominal 24-gauge steel for standard-duty applications. Optional insulation is available to enhance thermal and acoustic performance while maintaining simplified configuration options.

applications

Applications where a standard non-insulated door is needed.

Limitations

Available in sizes up to 20' wide x 16' high.

warranty

Standard hardware warranty is one year. Section warranty against rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | ThermaSeal TM175 | Raynor Garage Doors

Division

Insulated sectional steel door with 1-3/4" thick polyurethane core and 25-gauge exterior steel for durability and improved thermal performance.

applications

Ideal for any applications that require an insulated door.

Limitations

Available in sizes up to 36' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | ThermaSeal TM200 | Raynor Garage Doors

Division

High-performance insulated sectional door with U-Factor of 0.21 (R-Value 18.3), 2″ thickness, is engineered for enhanced energy efficiency in commercial applications.

applications

Applications with focus on high thermal efficiency and performance.

Limitations

Available in sizes up to 36' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | ThermaSeal TM200C | Raynor Garage Doors

Division

High-performance insulated sectional door with U-Factor of 0.17 (R-Value 18.3), 2″ thickness, is engineered for enhanced energy efficiency in commercial applications. Additional colors available.

applications

Applications where an insulated door with a large selection of standard colors is needed.

Limitations

Available in sizes up to 36' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | ThermaSeal TM220 | Raynor Garage Doors

Division

Heavy-duty, sectional, 20-gauge steel exterior door, 2″ thick with a U-Factor of 0.21 (R-Value 18.3).

applications

Ideal for heavy duty applications.

Limitations

Available in sizes up to 36' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | ThermaSeal TM300 | Raynor Garage Doors

Division

Insulated sectional steel door with advanced thermal and structural performance for demanding environments. 3″ thick door with U-Factor of 0.19 (R-Value 24.54).

applications

Ideal for applications requiring maximum thermal efficiency and long-term durability.

Limitations

Available in sizes up to 40' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details

083613 08-3613 08-3613. 08 36 13 08-36-13- Sectional Doors

Division 08

08 -

36

13 -

| - | ThermaSeal TM320 | Raynor Garage Doors

Division

Premium insulated sectional steel door with advanced thermal and structural performance for demanding environments. 3″ thick door with U-Factor of 0.19 (R-Value 24.54), 20-gauge exterior.

applications

Applications requiring the highest thermal efficiency and durability.

Limitations

Available in sizes up to 40' wide x 24' high.

warranty

Standard hardware warranty is one year. Section warranty against delamination and rust-through is ten years.

Warranty Details
